Red Utini 2set Raspberry Pi Module 2 DIY Proto HAT Shield for Raspberry Pi 2 Model B/B / A

Utini 2set Raspberry Pi Module 2 DIY Proto HAT Shield for Raspberry Pi 2 Model B/B + / A + (Red): Computers & Accessories. Utini 2set Raspberry Pi Module 2 DIY Proto HAT Shield for Raspberry Pi 2 Model B/B + / A + (Red): Computers & Accessories. Introduction。Design your own Pi HAT, attach custom circuitry and otherwise dress your Pi A+, B+, or Pi 2 with this jaunty prototyping HAT kit without EEPROM。To kick off the HAT party, we have this proto inspired plug in daughter board. It has a grid of 0.1" prototyping soldering holes for attaching chips, resistors, LED, potentiometers and more. The holes are connected underneath with traces to mimic the solderless breadboards you're familiar. There's also long power strips for +3V, +5V and Ground connections to the Pi. Near the top we break out nearly every pin you could want to connect to the Pi (#26 didnt quite make the cut).。A bit of light soldering is required to attach the header to the PCB but it's easy work.。This hat is only compatible with the Raspberry Pi A+, B+, or Pi 2! It will not work with the Raspberry Pi Model A or B.。 Packing List。1pcs*Proto HAT Shield。1pcs*2x20Pin。pcs*Nut。pcs*Screw。pcs*Stud Bolt。Renderings。If you need other Raspberry PI, please click the following link:。 。 。 。

Red Utini 2set Raspberry Pi Module 2 DIY Proto HAT Shield for Raspberry Pi 2 Model B/B / A
